Computer hardware requirements: CPU ---- clocked at 1.6G above; --- 1G RAM or more;

Computer System Requirements: WINDOWS system supports only the operating system, xp, win7-32 bit, win7-64 bit;

It supports the standard G-code files, such as * .nc, * tap and other tool path files;. Carved, SW, UG, PW, and other software to generate tool paths are supported;

It supports 4-axis, single-axis output frequency of up to 25K. 4-axis simultaneous maximum output frequency of 100K Hz;

It supports DXF files generated by CAD software; PLT / HPGL;

Support line cutting (need their own research);

It supports 4-axis limit function;

Support for knife function;

Support homing function;

Support tool change (need their own research);

Support spindle speed, switch control, water, spray control;

It supports all the features of the custom keyboard shortcuts;

CNC system supports most commonly used functions: Mirror, translation, circulation, and other functions;

Features:

1, compatible ESD, EMI, EMC requirements, simulation test results: compliance with IEC61000-4-2 level safety standards;

2, the use of opto-isolation design: the complete elimination of the limit relay and trigger large disturbance to the control board;

3, extensive use of TVS devices Interface Security,

4, the core chip all-metal shielding design;

5, using a custom dedicated USB cable; on the data lines, the inexpensive market provides noise immunity over blue USB 2.0 data line twice;

6, the first with hardware self-test function USB CNC NC card.
