PSVANE Hifi Vacuum Tube EL34C Generate UK-EL34 EL34B 6CA7 6P3P 6L6 5881 Free Pairing Amplifier Tubes

Original new tubes

Free pairing for multi quantity

EL34C
Series EL34 high performance audio output pentode, its anode limit dissipation power is 25W, in the audio amplifier single tube for class A1 amplifier output power is greater than 10W, double tube for class AB1 amplifier output power is greater than 35W.

EL34C is similar to EL34 and 6CA7 and can be used interchangeably.

Filament heater

UH……………………………6.3 V
IH……………………………1.5 A

Interelectrode capacitance

Input capacitance …………………… 15.2 PF
Output capacitance …………………… 8.4 PF
Cross capacitance …………………… 1.1 PF
Capacitance between hot wires of the first grid...... 1.0 PF
Capacitance between hot wire cathodes …………… 10 PF

Limit rating

Anode voltage ……………………… 800 V
Second gate voltage ………………… 500 V
First gate voltage ………………… -100 V
Anode dissipation power ………………… 25 W
Second gate dissipated power …………… 8 W
Cathode current ……………………… 150 mA

First gate resistance
From bias ……………………… 0.7 M Ω
Fixed bias …………………… 0.5 M Ω
Voltage between hot wire cathodes ……………… + 100 V
Shell temperature ……………………… 250 ℃

Static parameters

Ua…………………………… 250 V
Ug2……………………………250 V
Ug3…………………………… 0 V
-Ug1…………………………12.2 V
Ia…………………………… 100 mA
Gm…………………………… 11 mA/V
ri…………………………… 15 kΩ
μg1-g2………………………11

Packing list

1 Piece EL34C Tube

Pictures
